✅ Rated power: 12 kW (3-phase)

✅ Max PV input: 19,2 kW

✅ Battery voltage range: 40–60 V (48 V system)

✅ 2 × MPPT inputs: 350–650 V, 26 A each

✅ Peak efficiency: 97.6% | MPPT efficiency: >99%

✅ Dimensions: 386 × 660 × 253 mm

✅ Weight: 35.2 kg

✅ Rated power: 15 kW (3-phase)

✅ Battery voltage range: 40–60 V (48 V system)

✅ Max PV input: 30,000 W

✅ MPPT: 2 trackers (1 + 1) / range 200–650 V

✅ Max efficiency: 97.6% | MPPT >99%

✅ Dimensions: 456 × 750 × 268,5 mm

✅ Weight: 51,9 kg

✅ Rated power: 10 kW (3-phase)

✅ Max PV input: 15 kW

✅ Battery voltage range: 40–60 V (48 V system)

✅ 2 × MPPT inputs: 350–650 V, 26 A each

✅ Peak efficiency: 97.6% | MPPT efficiency: >99%

✅ Dimensions: 386 × 660 × 253 mm

✅ Weight: 35.2 kg

✅ Rated power: 20 kW (3-phase)

✅ Battery voltage range: 40–60 V (48 V system)

✅ Max PV input: 40,000 W

✅ MPPT: 2 trackers (1 + 1) / range 200–650 V

✅ Max efficiency: 97.6% | MPPT >99%

✅ Dimensions: 456 × 750 × 268,5 mm

✅ Weight: 51,9 kg

✅ Nominal power: 14 kW (3-phase)

✅ Battery voltage: 40–60 V (48 V)

✅ Max PV power: 28 000 W

✅ MPPT: 2 trackers / 2+2 strings

✅ MPPT range: 160–650 V

✅ Max efficiency: 97.6%

✅ MPPT efficiency: >99%

✅ Communication: WiFi, RS485, CAN, LCD/LED display

✅ Protection class: IP65

✅ Operating temperature: −40°C to +60°C

✅ Cooling: intelligent active cooling (≤55 dB)

✅ Protections: short-circuit, overcurrent, surge, thermal, RCD, RCM, AFCI, islanding detection, insulation monitoring

✅ Dimensions (mm): 456 × 750 × 268.5

✅ Weight: 51.9 kg

✅ Rated power: 16 kW (3-phase)

✅ Battery voltage range: 40–60 V (48 V system)

✅ Max PV input: 10,000 W

✅ MPPT: 2 trackers (1 + 1) / range 200–650 V

✅ Max efficiency: 97.6% | MPPT >99%

✅ Communication: WiFi, RS485, CAN, LCD/LED

✅ Protection rating: IP65

✅ Operating temperature: −40°C to +60°C

✅ Cooling: smart active cooling (≤55 dB)

✅ Protections: anti-islanding, AFCI, RCD, overcurrent, surge, DC insulation, short-circuit

✅ AC-coupling: yes – compatible with existing PV installations

✅ Peak overload: up to 2× power (10 s, off-grid mode)

✅ Dimensions: 386 × 660 × 250 mm

✅ Weight: 32.5 kg

✅ Rated power: 6 kW (three-phase)

✅ Battery voltage range: 40–60 V (48 V system)

✅ Max. PV input power: 12,000 W

✅ MPPT trackers: 2 (configuration 1+1)

✅ Dimensions: 386 × 660 × 253 mm

✅ Weight: 35.2 kg

✅ Rated power: 8 kW (3-phase)

✅ Max PV input: 12 kW

✅ Battery voltage range: 40–60 V (48 V system)

✅ 2 × MPPT inputs: 350–650 V, 26 A each

✅ Peak efficiency: 97.6% | MPPT efficiency: >99%

✅ Dimensions: 386 × 660 × 253 mm

✅ Weight: 35.2 kg
